| Specification | Weight (g/m) |
Break strength(N) |
Elongation (%) |
Average resistance(Ω) |
| 14μm×90×1 | 0.12 | 25 | 1.10% | 61 |
| 12μm×90×2 | 0.17 | 44 | 1.10% | 42 |
| 12μm×100×1 | 0.095 | 24 | 1.10% | 59 |
| 12μm×100×2 | 0.19 | 41 | 1.10% | 38 |
| 12μm×100×3 | 0.28 | 69 | 1.10% | 22 |
| 12μm×275×1 | 0.26 | 59 | 1.10% | 27 |
| 12μm×275×2 | 0.54 | 75 | 1.10% | 14 |
| 12μm×275×3 | 0.78 | 125 | 1.10% | 9 |
| 12μm×275×4 | 1.05 | 130 | 1.10% | 7 |
| 12μm×275×5 | 1.3 | 160 | 1.10% | 5 |
| 12μm×275×6 | 1.5 | 180 | 1.10% | 4 |
| 8μm×1000×1 | 0.42 | 69 | 1.10% | 16 |
| 8μm×1000×2 | 0.85 | 108 | 1.10% | 8 |
| 12μm×1000×1 | 0.95 | 100 | 1.10% | 7 |
| 12μm×1000×2 | 1.9 | 340 | 1.10% | 4 |
| Chemical Composition of Raw Materials (%) | |||||||||
| SUS 316L | C | Si | Mn | Ni | Cr | Mo | N | S | P |
| 0.02 | 0.60 | 0.82 | 11.1 | 16.9 | 2.04 | 0.03 | 0.0005 | 0.027 | |
